Instructions to Analyze Honeypot Data with Splunk

NOTE: These set up notes are now obsolete. I originally selected the free version of Splunk Enterprise as the solution to host the data generated by my Cowrie honeypot. That worked quite well, until one day I exceeded the daily data usage allowed under the free version license. At that point, I decided to migrate my data to a free and open-source solution that wouldn't impose data caps. I chose and implemented my current Cowrie analytics environment based on MySQL and the MySQL REST Service. The installation and configuration notes for that new approach are available here. The instructions on this page are based on the original, Splunk-base solution and are provided here as a reference.

As part of my cybersecurity research, these are the steps I took to implement a fully functional, fully automated honeypot data collection and analysis environment in my home lab:

Skip table of contents and pretty picture

I chose Cowrie as the key component of my unwanted traffic detection infrastructure. Cowrie is a superb medium/high interaction honeypot designed to log brute-force attempts and shell interactions launched by attackers over both SSH and Telnet. Cowrie is very popular among both researchers and enthusiasts due to an optimal combination of rich capabilities and ease of use. It is open-source and is backed by an active community led by Michel Oosterhof, the project's maintainer, creator, and main developer.

1. Choose the honeypot host

You need to start by choosing a Linux system where to install the honeypot. Since Cowrie is very efficient in its resource consumption, I opted for a tiny Raspberry Pi 400 computer as the Cowrie host.

2. Install the system dependencies

Install the system dependencies on the Cowrie host:


 $ sudo apt-get install git python3-virtualenv libssl-dev libffi-dev build-essential libpython3-dev python3-minimal authbind virtualenv

3. Create a user account

Installing a user without a password is not an absolute requirement, but it is recommended by the Cowrie authors:


 $ sudo adduser --disabled-password cowrie
 Adding user 'cowrie' ...
 Adding new group 'cowrie' (1002) ...
 Adding new user 'cowrie' (1002) with group 'cowrie' ...
 Changing the user information for cowrie
 Enter the new value, or press ENTER for the default
 Full Name []:
 Room Number []:
 Work Phone []:
 Home Phone []:
 Other []:
 Is the information correct? [Y/n]

 $ sudo su - cowrie

4. Get the Cowrie code

Clone the cowrie project from GitHub:


 $ git clone http://github.com/cowrie/cowrie
 Cloning into 'cowrie'...
 remote: Counting objects: 2965, done.
 remote: Compressing objects: 100% (1025/1025), done.
 remote: Total 2965 (delta 1908), reused 2962 (delta 1905), pack-reused 0
 Receiving objects: 100% (2965/2965), 3.41 MiB | 2.57 MiB/s, done.
 Resolving deltas: 100% (1908/1908), done.
 Checking connectivity... done.

 $ cd cowrie

5. Set up a Python virtual environment

Technically speaking, this step is not needed, but it is highly recommended to ensure that package updates on the Cowrie host system will not cause incompatibilities with the honeypot operation:


 $ pwd
 /home/cowrie/cowrie

 $ python -m venv cowrie-env
 New python executable in ./cowrie/cowrie-env/bin/python
 Installing setuptools, pip, wheel...done.

After you install the virtual environment, activate it and install required packages:


 $ source cowrie-env/bin/activate
 (cowrie-env) $ python -m pip install --upgrade pip
 (cowrie-env) $ python -m pip install --upgrade -r requirements.txt

6. Configure Cowrie

The Cowrie configuration is stored in the cowrie/etc/cowrie.cfg file. To run the honeypot with a standard configuration, there is no need to change anything. By default, Cowrie accepts traffic over SSH. I wanted the honeypot to also accept traffic over Telnet, send the data to Splunk (more on this later), and change the default ports 22 and 23, so I modified the configuration file as follows:


 [telnet]
 enabled = true
 ...
 [output_splunk]
 enabled = true
 ...
 [proxy]
 backend_ssh_port = 2022
 backend_telnet_port = 2023

I also wanted to change the default user configurations and the list of credentials accepted to login to the remote shell. These changes are made by modifing the cowrie/etc/userdb.txt file. Each line in the file consists of three fields separated by the : character, where:

Field #1 is the username.
Field #2 is currently unused and set to x.
Field #3 is the regular expression that specifies the list of passwords accepted by the user.

As an example, the following settings configure a username admin that accepts all passwords except 1) only numeric characters, 2) the case-sensitive string admin, and 3) the case-insensitive string honeypot:


 admin:x:!admin
 admin:x:!/^[0-9]+$/
 admin:x:!/honeypot/i
 admin:x:*

7. Customize Cowrie

Optionally, you can change the look-and-feel of the Cowrie interface to make it look more realistic. A number of files allow you to do that:

In cowrie/etc/cowrie.cfg, you can change, for example, the hostname displayed by the shell prompt, the user prompt, the Telnet username and password prompts, the response from the uname command, the SSH version printed by ssh -V, etc.


 hostname = appsrv02
 ...
 prompt = root>
 ...
 telnet_username_prompt_regex = (\n|^)ubuntu login: .*
 telnet_password_prompt_regex = .*Password: .*
 ...
 kernel_version = 3.2.0-4-amd64
 kernel_build_string = #1 SMP Debian 3.2.68-1+deb7u1
 hardware_platform = x86_64
 operating_system = GNU/Linux
 ...
 ssh_version = OpenSSH_7.9p1, OpenSSL 1.1.1a  20 Nov 2018

In cowrie/honeyfs/etc/issue, you can change the pre-login banner.
In cowrie/honeyfs/etc/motd, you can change the post-login message.
In cowrie/honeyfs/proc/cpuinfo, you can change the simulated CPU make-up of the system (e.g., number and type of processors).
In cowrie/honeyfs/proc/meminfo, you can change the simulated system's memory allocation and usage.
In cowrie/honeyfs/proc/version, you can change the Linux kernel and gcc versions.

8. Forward listening ports

As we saw above, I configured Cowrie to accept SSH traffic over port 2022 and Telnet traffic over port 2023. In order to preserve the fidelity of the decoy, I opened ports 22 and 23 on the router and forward their traffic to ports 2022 and 2023, respectively, on the system hosting Cowrie.

9. Start Cowrie

Start the honeypot by calling the cowrie/bin/cowrie executable that is part of the Cowrie distribution. An existing virtual environment is preserved if activated, otherwise Cowrie will attempt to load the environment called cowrie-env that we created earlier:


 bin/cowrie start
 Activating virtualenv "cowrie-env"
 Starting cowrie with extra arguments [] ...

I opted for Splunk Enterprise as the warehouse of my Cowrie-generated data because it is very powerful, offers superb API-based data querying and manipulation functionality, can be installed locally, and — best of all — is free if you keep your data volume under 500MB per day. I found it easier to set up and operate than alternatives such as Elasticsearch/OpenSearch and Graylog.

1. Install Splunk

Splunk Free is a free (as in no-cost) version of Splunk Enterprise with limited capabilities. When you first install Splunk Enterpise, it will automatically install an Enterprise Trial license that comes enabled by default. The Splunk Enterprise Trial license is valid for 60 days. The best part is that you can switch to the free license at any time during the trial period. The steps are as follows:

Navigate to the Splunk Enterprise page.
If you do not have a Splunk account, create one.
Log into your Splunk account.
Under Products, select Free Trials and Downloads, scroll down to Splunk Enterprise, and click the Get My Free Trial button.
Select the operating system of the machine where you want to install Splunk (I chose Windows), then download the latest version of Splunk Enterprise by clicking on the Download Now button.
Agree to the Splunk General Terms and click Access Program to start the download.
Open the downloaded package and follow the installation instructions on your operating system of choice.

2. Switch from Splunk Enterprise to Splunk Free

At any time during your Splunk Enterprise trial, you can switch to the Free license. This is how:

Login to your administrator account on the web interface of Splunk Enterprise. The default URL is http://127.0.0.1:8000.
In the upper right-hand corner, navigate to Settings.
Under System, select Licensing.
Select Change License Group.
Select Free license and then click Save.
On the next screen, select Restart Now for the changes to take effect.

3. Create a Splunk HTTP event collector (HEC)

Navigate to the web interface of your Splunk instance at http://127.0.0.1:8000.
In the upper right-hand corner, select Settings.
Under Data, select Data Inputs.
Under Local Inputs, click the HTTP Event Collector link.
Under HTTP Event Collector, click the Global Settings button at the top right of the page.
Under Edit Global Settings, click Enabled, then click the Save button.
Go back to Data > Data Inputs.
Under Local Inputs, click +Add new to the right of HTTP Event Collector.
Under Add Data, enter a name for your new HEC, then click Next.
Under Input Settings, click the Create a new index link in the Index section.
Under New Index, enter cowrie as the name of your new index, then click Save.
Back under Input Settings, select your newly-created index under Select Allowed Indexes, then click the Review button at the top right of the page.
Under Review, click the Submit button at the top right of the page.

4. Create a Splunk event collector token

Navigate to the web interface your Splunk instance at http://127.0.0.1:8000.
In the upper right-hand corner, select Settings.
Click the Add Data icon.
Under Or get data in with the following methods, click Monitor.
Click HTTP Event Collector.
Enter a name for the token.
Click the Next button at the top right of the page.
Click the Review button at the top right of the page.
Under Review, click the Submit button at the top right of the page.
Copy the token value; you will need it in the next step.

5. Configure Cowrie to use the Splunk event collector

We now need to go to back the Cowrie configuration file cowrie/etc/cowrie.cfg and make edits to ensure that Cowrie sends the events it collects to Splunk through the HEC we created earlier. Look for the [output-splunk] section and ensure that it looks like this:


 [output-splunk]
 enabled = true
 url = http://XXX.XXX.XXX.XXX:8088/services/collector/event
 token = your_splunk_token
 index = cowrie
 sourcetype = cowrie
 source = cowrie

Replace the XXX.XXX.XXX.XXX part of the url setting with the local IP address on your home network of the system hosting your Splunk instance. Replace your_splunk_token in the token setting with your Splunk token. Leave the index, sourcetype, and source settings set to their cowrie default.

6. Verify that everything works

If all the above configuration steps went well, you should now have Cowrie connected to Splunk. Start Cowrie on the system where it was installed (Raspberry Pi in my case) and make sure that your Splunk service is running on the system where you installed it; mine runs on Windows 11. Assuming that your honeypot is being attacked — a very safe bet — you should see nicely formatted events on your Splunk instance. To view them, select Apps > Search & Reporting from your Splunk web interface and enter the following in the New Search text field:


 index=cowrie

That is all. Happy threat hunting!
